I had a difficult time finding good examples working with the JQuery Portlets, so I created by own. Based on the Portlet Example, here is source code that demonstrates the following features:
- Draggable & Sortable
- Different Sized Columns
- Close Button
- Settings Menu
- Change Visibility Of Each Portlet
- Change Column Widths
- Scrollable Portlet Contents
Visit the Live Demo. Download the source code at GitHub.
dashboard.html
<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"
"http://www.w3.org/TR/html4/loose.dtd">
<html>
<head>
<meta http-equiv="Content-type" content="text/html; charset=utf-8">
<title>Sample Dashboard</title>
<link rel='stylesheet'
href='http://ajax.googleapis.com/ajax/libs/jqueryui/1.7.2/themes/cupertino/jquery-ui.css'/>
<script src='http://ajax.googleapis.com/ajax/libs/jquery/1.3.2/jquery.js'></script>
<script src='http://ajax.googleapis.com/ajax/libs/jqueryui/1.7.2/jquery-ui.js'></script>
<link rel='stylesheet' href='dashboard.css'/>
<script src="dashboard.js" type="text/javascript" charset="utf-8"></script>
</head>
<body id="dashboard">
<div id='header' class="ui-widget-header ui-corner-all ui-widget">
<div>Dashboard test</div>
<div id="menu2" class="ui-icon ui-icon-wrench"></div>
<br class='clear'/>
</div>
<div class="demo">
<div id="window_dialog" class="hidden">
<fieldset>
<legend>Column Widths</legend>
<label>Left:</label><input type='text' id='c1-width'>
<label>Middle:</label><input type='text' id='c2-width'>
<label>Right:</label><input type='text' id='c3-width'>
</fieldset>
<fieldset>
<legend>Window Visibility</legend>
<input type="checkbox" id="feeds-visible" /><label>Feeds</label><br/>
<input type="checkbox" id="shopping-visible" /><label>Shopping</label><br/>
<input type="checkbox" id="news-visible" /><label>News</label><br/>
<input type="checkbox" id="links-visible" /><label>Links</label><br/>
<input type="checkbox" id="images-visible" /><label>Images</label><br/>
</fieldset>
</div>
<div class="column1">
<div id='feeds-portlet' class="portlet">
<div class="portlet-header">Feeds</div>
<div class="portlet-content">Lorem ipsum dolor sit amet, consectetuer adipiscing elit</div>
</div>
<div id="news-portlet" class="portlet">
<div class="portlet-header">News</div>
<div class="portlet-content">Lorem ipsum dolor sit amet, consectetuer adipiscing elit</div>
</div>
</div>
<div class="column2">
<div class="portlet" id='shopping-portlet'>
<div class="portlet-header">Shopping</div>
<div class="portlet-content">Lorem ipsum dolor sit amet, consectetuer adipiscing elit</div>
</div>
</div>
<div class="column3">
<div id="links-portlet" class="portlet">
<div class="portlet-header">Links</div>
<div class="portlet-content">Lorem ipsum dolor sit amet, consectetuer adipiscing elit</div>
</div>
<div id="images-portlet" class="portlet">
<div class="portlet-header">Images</div>
<div class="portlet-content">Lorem ipsum dolor sit amet, consectetuer adipiscing elit
Lorem ipsum dolor sit amet, consectetur adipisicing elit, sed do eiusmod tempor
incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud
exercitation ullamco laboris nisi
</div>
</div>
</div>
</div>
</body>
</html>
dashboard.css
body{min-width: 900px;}
h1{color: red;}
.button{padding: 5px; border: 1px solid gray;}
.column1 { width: 170px; float: left; padding-bottom: 100px; }
.column2 {width: 500px; float: left; padding-bottom: 100px; }
.column3 { width: 170px; float: left; padding-bottom: 100px; }
.portlet { margin: 0 1em 1em 0; }
.portlet-header { margin: 0.3em; padding-bottom: 4px; padding-left: 0.2em; }
.portlet-header .ui-icon { float: right; }
.portlet-content { padding: 0.4em; }
.ui-sortable-placeholder { border: 1px dotted black; visibility: visible !important; height: 50px !important; }
.ui-sortable-placeholder * { visibility: hidden; }
.portlet-content {
max-height:200px;
_height:expression(this.scrollHeight>199?"200px":"auto");
overflow:auto;
overflow-x:hidden;
}
.hidden{display: none}
#header{margin-bottom: 5px; padding: 3px}
#header div{float: left;}
#menu2{float:left;}
br.clear{clear:both;}
dashboard.js
var portlets = ["feeds", "shopping", "news", "links", "images"];
$(document).ready(function () {
$('#menu2').click(function(event) {
$('#window_dialog').dialog({
autoOpen: true,
draggable: false,
modal: true,
title: 'Settings',
buttons: {
"Save": function () {
$(portlets).each(function() {
set_window_visibility(this);
});
$(".column1").width(parseInt($('#c1-width').val()));
$(".column2").width(parseInt($('#c2-width').val()));
$(".column3").width(parseInt($('#c3-width').val()));
$(this).dialog('destroy');
},
"Cancel": function () {
$(this).dialog('destroy');
}
}
});
});
function set_window_visibility(name){
if($('#'+name+'-visible').is(':checked'))
$('#'+name+'-portlet').show();
else
$('#'+name+'-portlet').hide();
}
function set_visible_check(name){
if($('#'+name+'-portlet').is(":visible"))
$('#'+name+'-visible').each(function(){ this.checked = true; });
else
$('#'+name+'-visible').attr("checked", false);
}
$( "#settings_dialog" ).bind( "dialogopen", function(event, ui) {
});
$( "#window_dialog" ).bind( "dialogopen", function(event, ui) {
$(portlets).each(function() {
set_visible_check(this);
});
$('#c1-width').val($(".column1").width());
$('#c2-width').val($(".column2").width());
$('#c3-width').val($(".column3").width());
});
});
$(function() {
$( ".column1" ).sortable({
connectWith: ".column1, .column2, .column3"
});
$( ".column2" ).sortable({
connectWith: ".column1, .column2, .column3"
});
$( ".column3" ).sortable({
connectWith: ".column1, .column2, .column3"
});
$( ".portlet" ).addClass( "ui-widget ui-widget-content ui-helper-clearfix ui-corner-all" )
.find( ".portlet-header" )
.addClass( "ui-widget-header ui-corner-all" )
.prepend( "<span class='ui-icon ui-icon-closethick icon-close'></span><span class='ui-icon ui-icon-minusthick icon-vis'></span>")
.end()
.find( ".portlet-content" );
$( ".icon-vis" ).click(function() {
$( this ).toggleClass( "ui-icon-minusthick" ).toggleClass( "ui-icon-plusthick" );
$( this ).parents( ".portlet:first" ).find( ".portlet-content" ).toggle();
});
$( ".icon-close" ).click(function() {
$( this ).parents( ".portlet:first" ).hide();
});
$( ".column" ).disableSelection();
});
